Outdoor Pedestal IP Intercom

Wahsega’s Outdoor Pedestal IP Intercom is a rugged intercom designed for outdoor use. Available in single-button and two-button configurations, each Outdoor Pedestal IP Intercom has an on-board relay for access control. Integrated microphone and speaker provide crisp, clear audio for two-way SIP calls and incoming Carina broadcasts. The optional hood is recommended for uncovered installations to prevent damage from the elements.

Intercom Only: $249

Carina Model Number WL-IC-BKMT-SIP-OV-R-CAR



Small IP Display

Intercom + Hood: $299

Carina Model Number WL-IC-BKMT-SIP-OV-R-CAR

Hood Model Number WL-BKMT-HOOD-OV

Outdoor IP Intercom with hood accessory

Designed specifically for outdoor use, the Wahsega Outdoor Pedestal IP Intercom is a workhorse IP solution for gate and entry intercom needs. Its steel construction and tough exterior house an integrated speaker, microphone and relay as well as circuit board with conformal coating. Add the optional weather hood to protect it from the elements.

Rear conduit and fastener access make this intercom perfect for mounting on a wall or standard gooseneck pedestal near an entry access point. Register the Outdoor Pedestal IP Intercom as an extension on your VoIP phone system, and users can call a preconfigured number on that system. Crisp, two-way audio ensures that parties on both ends of the call can clearly communicate. Users can also stream background music or send alerts using Carina.

The Outdoor Pedestal IP Intercom’s integrated relay lets users open gates or unlock doors at the intercom or remotely. The relay can be triggered by a SIP call or Carina broadcast, or it can be configured to actuate when a remote caller enters a code.

The Outdoor Pedestal IP Intercom can be managed by the Carina Event Manager or Event Manager Lite.

Highlights

  • Two-way VoIP endpoint
  • Integrated speaker and microphone
  • On-board relay
  • Advanced panic button functionality
  • IP65 Rated for outdoor use
  • Rear conduit access for pedestal mounting
  • Supports Carina and SIP

Safety Certification Seals

Using Power-over-Ethernet (PoE) for data and power, the Outdoor Pedestal IP Intercom is simple to set up and install. An integrated relay and rear conduit access for pedestal mounting make it the perfect solution for access control at gates and entry points.

Users place a call by simply pressing a button on the intercom, which dials a preconfigured SIP extension. Clear, full-duplex Voice over IP (VoIP) audio with background noise suppression and audio filters ensures smooth conversations.

Advanced panic button functionality allows the Outdoor Pedestal IP Intercom to dial one number with a short button press and different number with a longer press and hold. With this function, the intercom can connect with both a front desk and a security desk, for instance, sending fewer false alarms to the security desk.

Available in single-button and two-button and configurations, the intercom’s second button may be used to call a different number or to activate a relay. During the call, users at either end can activate the Outdoor Pedestal IP Intercom’s onboard relay to unlock a door, lift a gate arm, or trigger a security device such as a strobe.

The Outdoor Pedestal IP Intercom can receive inbound calls and stream RTP multicast audio at multiple priority levels. This allows users to stream background music without affecting SIP calls and to broadcast emergency announcements without interruptions.

Programming the Outdoor Pedestal IP Intercom is simple, and LED feedback on the intercom lets installers know when their system is up and running. The intercom supports the SIP protocol so it can register with the Wahsega PICS, Diet IP PBX or any IP PBX for easy integration with your existing phone system. The best way to manage this device is through the Carina Event Manager or Event Manager Lite.

With simple installation and programming, advanced functionality and reduced labor and installation costs, the Outdoor Pedestal IP Intercom is the perfect solution for a wide range of indoor or outdoor applications.

Features

  • Fully configurable via Wahsega Carina Event Manager
  • SIP Compliant
  • PoE 802.3af power
  • Environmental noise suppression
  • Full-duplex audio with Acoustic Echo Cancellation (AEC)
  • Peer-to-peer SIP capable
  • Paging speaker function
  • On-board relay for door latches
  • Mic and speaker volume control
  • IP65 weather protection (conformal coated internal circuity)
  • Optional weather hood
  • Security screws included
  • Ethernet:
  • 10/100 Mbps (Can force 10Mbps full-duplex)
  • Protocol: SIP RFC 3261 compatible
  • Temperature Range: -40°C to +60°C
  • Audio Codecs: G.711 uLaw, G.711 aLaw, G.722 HD, G.726 fixed payload, G.729, DVI4 HD, DVI4 Narrowband, OPUS
  • Audio Sampling: Up to 48KHz
  • Form C (SPDT) Relay Contact Closure Rating: 30VDC or 270VAC, 3A
  • Dimensions: 5.96″ x 5.88″ x 2.88″ (H x W x D)
  • Warranty: 2 years limited
  • Regulatory Compliance: FCC Class B
  • Power
  • Input: PoE 802.3af

Carina Documentation:

Installation Documentation:
